79NM (79НМ) Precision Alloy

79NM (79НМ) Precision Alloy
Inquiry
Chemical Composition in % for Grade 79NM (79НМ)
Fe C Si Mn Ni S P Mo Ti Al Cu
13.73 - 16.8 ≤0.03 0.3 - 0.5 0.6 - 1.1 78.5 - 80 ≤0.02 ≤0.02 3.8 - 4.1 ≤0.15 ≤0.15 ≤0.2
Mechanical Properties under Т=20oС for Grade 79NM (79НМ)
Assortment Tensile Strength Yield Stress Specific Elongation at Fracture
- MPa MPa %
Band, GOST 10160-75 490 145 50
Band cold-worked , GOST 10160-75 1030 980 3

Brinell Hardness for 79NM (79НМ) Band GOST 10160-75: Brinell hardness 10-1 = 210 MPa
Band GOST 10160-75: Brinell hardness 10-1 = 120 MPa

Physical Properties for Grade 79NM (79НМ)
Test Temperature Young Modulus 10-5 Coefficient of Linear Expansion 106 Density Electrical Resistance 109
Grade MPa 1/Grade kg/m3 Ohm·m
20 2.1   8600 550
100   10.5
