Incoloy A-286 Nickel Alloy

The Incoloy A-286 nickel alloy is an iron-nickel-chromium alloy with additions of molybdenum, titanium, aluminum, vanadium and trace amount of boron that stiffen the alloy matrix, thus providing high mechanical strength. At the temperature under 650℃, the alloy A-286 boasts extremely high yield strength and creep-rupture strength as well as great fabrication characteristics and weldability.

These superior prosperities of this high temperature alloy make it useful for high temperature bearing components of aircraft engine, such as turbine disc, compressor disc, rotor blade and fastener.

Specifications of Incoloy A-286 nickel alloy
UNS W. Nr
S66286 1.4980
Chemical Compositions
Composition Ni Cr Mo B P Al Ti C Mn Si V S Fe
Content (%) Min 24 13.5 1.0 0.001 1.75 0.10 Bal.
Max 27 16 1.5 0.01 0.03 0.40 2.35 0.08 2.0 1.0 0.50 0.02
Mechanical Properties (Minimum value at 20℃)
Tensile Strength (σb/MPa) Yield Strength (σp0.2/MPa) Elongation (σ5/%)
610 270 30
Product Forms and Standards
Bar Forging
ASTM B638 ASTM B638
